Performance

Model

X8-M20

X8-M20D

X8-M21

X8-M21D X8-M22
Tracking GPS, BDS, GLO, GAL, QZSS, NavIC

Horizontal Positioning Accuracy

Single Point

1.5 m (RMS)

RTK

1 cm + 1 ppm (RMS)

Vertical Positioning Accuracy

Single Point

2.5 m (RMS)

RTK

1.5 cm + 1 ppm (RMS)

Heading Accuracy

0.2°/1m

0.2°/1m

DR Accuracy*

0.8%(2σ)

0.8%(2σ)

0.2%(2σ)

Number of Antenna

1

2 1 2 1
Max Transfer Rate GNSS Messages

10Hz

10Hz

5Hz

5Hz 5Hz
INS Messages

100Hz

100Hz

100Hz

First Positioning Time

Cold start

30 s (Typ.)

Hot start

5 s (Typ.)

 *Optional, it requires wheelspeed input



Optimizing Performance for Every Need

Applications

Designed for flexibility, the X8-M1 can be used for personnel tracking, vehicle positioning or pinpointing on centering rods. Additionally, it includes features such as electronic fencing, proximity detection for high-voltage power lines, enhancing both safety and operational efficiency.

Ensuring Excellence in Every Step

Mass Production and Quality

Bynav has all-round automotive certificates, sophiscated equipment and fully-automated production lines to ensure mass production capacity as well as reliable and high-quality products.

GNSS/INS Positioning Box

Automated Production Lines

To ensure the quality and consistency of assembly and testing of boxes and modules.



Automotive Certificates

ISO 26262 ASIL B (Product), ISO 26262 ASIL D (Management) , ISO/SAE 21434, AEC-Q104, AEC-Q100, ASPICE, IATF 16949.



Smart Management Systems

To record key data throughout the entire product life cycle and make every process traceable and manageable.



Experimental Capability

IMU Calibration Center, GNSS Laboratory, Functional Test, Durability/Environmental Test, Optical/Vision Inspection.
